SharkBite PEX tubing is a cross-linked polyethylene tubing for a wide range of residential and commercial plumbing applications. Manufactured with an oxygen barrier for radiant floor and hydronic heating applications (available in orange). The oxygen diffusion barrier applied to the exterior limits oxygen permeation through the tubing wall in hydronic heating applications which prevents corrosion of ferrous metal parts in the heating system. A repeating SharkBite imprint pattern provides a visual aid to determine if the tube has been inserted all the way into the SharkBite Push-to-Connect Fitting. This feature only works if the tubing is cut between the SharkBite imprint pattern.
Item Weight |
5.0 |
Application |
Potable Water |
Connectivity |
Push Fit |
Color Family |
Orange |
Color/Finish |
Orange |
Product Weight (lb.) |
5 |
Pipe Features |
Flexible |
Returnable |
180-Day |
Pipe or Fitting Product Type |
Pipe & Tubing |
Minimum working temperature (F) |
32 |
Material |
Cross-Linked Polyethylene (PEX) |
PEX Type |
C |
Maximum working pressure (psi) |
160 |
Pack Size |
1 |
Maximum Flow Rate (gallons per minute) |
4.4 |
Maximum Working Temperature (F) |
200 |
Pipe Wall Thickness (In.) |
.15 |
Product Length (ft.) |
100 ft |
Nominal Inside Pipe Diameter (In.) |
1/2" |
Actual outside diameter (in.) |
.625 |
Actual inside diameter (in.) |
0.475 |
Certifications and Listings |
ANSI Certified,CSA Listed,IAPMO Certified |
Manufacturer Warranty |
For warranty information on this product, please call our Internet Customer Service Center at 1-800-435-4654. |
